| 型號： | 2N3904 |
| 廠商： | NATIONAL SEMICONDUCTOR CORP |
| 元件分類： | 小信號晶體管 |
| 英文描述： | 200 mA, 40 V, NPN, Si, SMALL SIGNAL TRANSISTOR, TO-92 |
| 封裝： | TO-92, 3 PIN |
| 文件頁數： | 2/4頁 |
| 文件大?。?/td> | 98K |
| 代理商： | 2N3904 |
NPN General Purpose Amplifier
(continued)
Electrical Characteristics
TA = 25°C unless otherwise noted
Symbol
Parameter
Test Conditions
Min
Max
Units
V(BR)CEO
Collector-Emitter Breakdown Voltage
IC = 10 mA, IB = 040V
V(BR)CBO
Collector-Base Breakdown Voltage
IC = 10
A, I
E = 0
60
V
V(BR)EBO
Emitter-Base Breakdown Voltage
IE = 10
A, I
C = 0
6.0
V
IBL
Base Cutoff Current
VCE = 30 V, VEB = 0
50
nA
ICEX
Collector Cutoff Current
VCE = 30 V, VEB = 0
50
nA
OFF CHARACTERISTICS
ON CHARACTERISTICS*
SMALL SIGNAL CHARACTERISTICS
SWITCHING CHARACTERISTICS (except MMPQ3904)
*Pulse Test: Pulse Width ≤ 300 s, Duty Cycle ≤ 2.0%
NPN (Is=6.734f Xti=3 Eg=1.11 Vaf=74.03 Bf=416.4 Ne=1.259 Ise=6.734 Ikf=66.78m Xtb=1.5 Br=.7371 Nc=2
Isc=0 Ikr=0 Rc=1 Cjc=3.638p Mjc=.3085 Vjc=.75 Fc=.5 Cje=4.493p Mje=.2593 Vje=.75 Tr=239.5n Tf=301.2p
Itf=.4 Vtf=4 Xtf=2 Rb=10)
Spice Model
2N3904
/
MMBT3904
/
MMPQ3904
/
PZT3904
fT
Current Gain - Bandwidth Product
IC = 10 mA, VCE = 20 V,
f = 100 MHz
300
MHz
Cobo
Output Capacitance
VCB = 5.0 V, IE = 0,
f = 1.0 MHz
4.0
pF
Cibo
Input Capacitance
VEB = 0.5 V, IC = 0,
f = 1.0 MHz
8.0
pF
NF
Noise Figure (except MMPQ3904)
IC = 100
A, V
CE = 5.0 V,
RS =1.0k
, f=10 Hz to 15.7 kHz
5.0
dB
td
Delay Time
VCC = 3.0 V, VBE = 0.5 V,
35
ns
tr
Rise Time
IC = 10 mA, IB1 = 1.0 mA
35
ns
ts
Storage Time
VCC = 3.0 V, IC = 10mA
200
ns
tf
Fall Time
IB1 = IB2 = 1.0 mA
50
ns
hFE
DC Current Gain
IC = 0.1 mA, VCE = 1.0 V
IC = 1.0 mA, VCE = 1.0 V
IC = 10 mA, VCE = 1.0 V
IC = 50 mA, VCE = 1.0 V
IC = 100 mA, VCE = 1.0 V
40
70
100
60
30
300
VCE(sat)
Collector-Emitter Saturation Voltage
IC = 10 mA, IB = 1.0 mA
IC = 50 mA, IB = 5.0 mA
0.2
0.3
V
VBE(sat)
Base-Emitter Saturation Voltage
IC = 10 mA, IB = 1.0 mA
IC = 50 mA, IB = 5.0 mA
0.65
0.85
0.95
V
