MX07 B-49
B
2.00
to
2.50mm
(.079
to
.098")
Pitch
PCB
and
Wire
Co
nnectors
2.50mm (.098") Pitch
Mini-SPOX
Wire-to-Board
Header
5268-NA
Right Angle
Fully Shrouded
Features and Benefits
■
Sizes2to15circuits
■
0.70mm(.027")roundpins
■
Polarized
■
Frictionlock
Reference Information
Packaging:Bag
ULFileNo.:E29179
CSAFileNo.:LR19980
MatesWith:5264-Nand42219
DesignedIn:Millimeters
Electrical
Voltage:250V
Current:
AWG
22
24
26
28
3.0A
2.5A
2.0A
1.5A
ContactResistance:20milliohmsmax.
DielectricWithstandingVoltage:1000VAC/1min.
InsulationResistance:1000Megohmsmin.
Physical
Housing:6/6nylon,UL94V-0
Contact:Brass
Plating:Tin
OperatingTemperature:-40to+105C
Circuits
Order No.
Lead-free
2
Yes
3
4
5
6
7
8
Circuits
Order No.
Lead-free
9
Yes
10
11
12
13
14
15
2.50mm (.098") Pitch
SPOX
Wire-to-Board
Header
42249
Shrouded, Staggered Footprint
Features and Benefits
■
Polarizedtomatingconnector
■
Staggeredfootprintpreventssolderbridging
■
StandardkinkedPCtailsforretentiontoPCboard
Reference Information
ProductSpecification:PS-42219
Packaging:Bag
ULFileNo.:E29179
CSAFileNo.:LR19980
MatesWith:42219connectors
DesignedIn:Millimeters
Electrical
Voltage:250V
Current:3.0A
ContactResistance:20milliohmsmax.
DielectricWithstandingVoltage:1000VAC
InsulationResistance:1000Megohmsmin.
Mechanical
MatingForce:1.8kgmax.percircuit
UnmatingForce:0.15kgmin.percircuit
Durability:25cycles
Physical
Housing:Polyester,UL94V-0
Contact:Brass.027"diameter
Plating:Tin
OperatingTemperature:0to+75C
Circuits
Order No.
Lead-free
2
Yes
3
4
5
6
7
8
Circuits
Order No.
Lead-free
9
Yes
10
11
12
13
14
15
