AMIS-49200
-
Fieldbus
MAU
Chip
Feature
Sheet
Normal Operating Conditions
AMIS-49200
-
Fieldbus
MAU
Chip
Feature
Sheet
AMI Semiconductor
AMIS-49200 Fieldbus MAU Chip
Product Description
IEC-61158-2, H1 (ISA-S50.02-1992), Type 111 and
Type 112 (FF-816) compliant
-40°C to 85°C
44-pin plastic LQFP (Green/RoHS compliant)
Low current consumption: 500A typical
Standard MDS/MAU interface
31.25kbps voltage mode
Dual voltage regulators (3 and 6.2V)
Voltage level monitoring
Key Features
The AMIS-49200 Fieldbus Medium Attachment Unit
(MAU) can be used in applications that meet the
Foundation Fieldbus and Profibus PA standards. It is
compatible with requirements of the IEC-61158-2, H1
(ISA-S50.02-1992, EN 50170 (formerly DIN 19245))
physical layer standard.
The AMIS-49200 Fieldbus MAU is a near pin-for-pin
replacement for Yokogawa SAA22Q. This includes the
elimination of some capabilities and specifications of the
SAA22Q.
In most applications, the AMIS-49200 can be used as a
replacement for the SAA22Q. Some external component
values may have to be changed but, in most cases, the
layout of the circuit board will not have to change.
Parameter
Symbol
Min.
Typ.
Max.
Units
Conditions
Analog Supply Voltage
VCC
4.75
5
6.2
V
Supply voltages are configurable or can be
supplied from off-chip
Digital Supply Voltage
VDD
2.7
3
VCC - 1.1V
V
Supply voltages are configurable or can be
supplied from off-chip
Operating Temperature
Toperating
-40
85
°C
Current Compensation
ICC
500
800
A
25°C, SHUNT current = 1mA,
No current from series regulator
CMOS Parameter Specifications
CMOS Parameter Specs
Symbol
Min.
Max.
Units
Input High Voltage
VIH
0.7
VDD
VDD
V
Input Low Voltage
VIL
0
0.3
VDD
V
Input High Current
IIH
1
A
Input Low Current
IIL
-1
A
Schmitt Negative Threshold
Vt-
0.2
VDD
V
Schmitt Positive Threshold
Vt+
0.8
VDD
V
Schmitt Hysteresis
Vh
1
V
Ordering Codes
Marketing Name
Description
Device No.
AMIS-49200
Fieldbus MAU Chip
19699-002-XTD (tray) or -XTP (tape & reel)
EVK-49200
AMIS-49200 Evaluation Kit EVK-49200
