1825198-1
Active
Slide Switches
Alway s EU Ro HS/ELV Co mplian t
(Statemen t o f Comp lian ce)
Product Highlights:
Number of Positions = 3
Double Pole - Three Throw Configuration (Pole-Throw)
Actuator Sty le = Extended, Top
Actuator Color = Black
MSSA Series
View all Features | Find Sim ilar Products
Previous 1 2 3 4 [5] ... 20 Next
Quick Links
Check Pricing & Availability
Search for Tooling
Product Feature Selector
Compare Products
Contact U s About This
Product
Documentation & A dditional Information
Product Drawings:
None Available
Catalog Pages/Data Sheets:
None Available
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
Additional Information:
Product Line Inform ation
Related Products:
Tooling
Product Features
(Please use the Product Drawing f or all design activity)
Product Type Features:
Number of Positions = 3
Configuration (Pole-Throw) = Double Pole - Three Throw
Actuator Sty le = Extended, Top
Mount Angle = Vertical
Grade = Instrumentation
Term ination Type = PC
PCB Retention Feature = Yes
Electrical Characteristics:
Contact Rating = 0.4 VA m ax @ 20 VDC or peak AC, 300mA @ 125 VAC
Body Related Features:
Actuator Color = Black
Series = MSSA
Mount Sty le = Through-Hole
PCB Tail Length (mm [in]) = 3.51 [0.136]
PCB Retention Method = Guide Posts
Actuator Length (mm [in]) = 10.40 [0.410]
Actuator Material = Poly ester
Flamm ability Rating = UL 94V -0
Actuator Travel = 2.50 [.098]
Contact Related Features:
Contact Plating = Silver
Configuration Related Features:
Term inal Configuration = Standard
Number of Actuators = Single
Industry Standards:
RoHS/ELV Compliance = RoHS compliant, ELV com pliant
Lead Free Solder Processes = Wave solder capable to 240C, Wave solder capable to 260C, Wave
solder capable to 265C
RoHS/ELV Compliance History = Alw ay s was RoHS compliant
Identification Marking:
Stamped Marking = W ith
Other:
Brand = Alcoswitch
