DRAWING NUMBER
07595
DATE:
8/07
FOOT GROUND, TOE, CONDUCTIVE
Description:
The 07595 premium toe grounder provides effective ESD protection. The
cup is made from a black and non-marring rubber with inner tear resistant
conductive scrim. The rubber is antistatic, low tribocharging, and dissipative. It removes
charges when in contact with ESD protected floors. This foot grounder meets the less
than 3.5 x 106 ohm requirement of ANSI ESD S20.20. This unit includes a two megohm
molded external resistor, a conductive tab with carbon suffused fibers, and a D-ring
fastening system. The product has been tested to ESD STM 97.2 - Floor Materials and
Footwear Voltage Measurement in Combination with a Person. It is a suitable ESD
footwear component in Flooring - Footwear System when used as the primary
grounding method (<3.5 x 107 ohms per ESD STM 97.1 Floor Materials and Footwear-
Resistance Measurement in Combination with a Person.)
Components:
A. 0.060" thick, 1.50" wide, black conductive exterior with a non-marring interior. Tear
resistant nylon reinforced 4.3 oz. inner scrim layer prevents the rubber from tearing.
B. 3/8" wide, 30" long blue polyester tab contains electrically conductive carbon
suffused fibers.
C. 3/4" wide, blue loop material with return hook tip for quick and easy adjustment and
wearer's comfort.
D. 3/4" wide blue elastic material stretches for comfort.
E. D-ring fastening system.
F. A 1/4 watt, 2 megohm black molded external resistor.
listed for safety and date coded.
Tab to cup resistance:
106 - 107 Ohms @ 100 volts
D
C
B
F
A
DESCO WEST: 3651 WALNUT AVE., CHINO, CA 91710 WEB SITE: www.desco.com
PHONE (909) 627-8178 FAX (909) 627-7449
DESCO EAST: 90 HUDSON RD, CANTON, MA 02021-1407
PHONE (781) 821-8370 FAX (781) 575-0172
ITEM #
DESCRIPTION
07595
Foot Ground, Toe, 2 megohm resistor, RTG: 106 - 107 Ohms
Our UL listed foot grounders are rated at 250 VAC. It is not recommended to use them where exposure
to line voltages above 250 VAC is possible. Caution: The foot grounder is for ESD control. It will not
reduce or increase your risk of receiving electric shock when using or working on electrical equipment.
Note:
Two heel straps are recommended for reliable grounding and ESD protection,
providing ground when one foot is off the floor.
Operator is grounded when foot is in contact with grounded dissipative or
conductive flooring.
Desco recommends the use of foot ground tester item No. 19252 or 19253.
For additional information on the use and maintenance of foot grounders please
ask for Technical Bulletins TB-2020 and TB-2040.
Item 07595 is UL listed.
E
2007 DESCO INDUSTRIES INC.
Employee Owned
Made in America
90P1
LISTED
