This document was generated on 12/01/2009
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Active
Overview:
Description:
2.36mm (.093") Diameter, .093" Pin and Socket Receptacle Housing with Positive
Latch, 6 Circuits, Without Mounting Ears, Glow Wire Compatible
Documents:
General
Product Family
Crimp Housings
Series
Comments
Polarized to Mating Part, Nylon PA 6, UL94 V-0
Overview
Standard .093"
Product Name
Standard .093"
Physical
Breakaway
No
Circuits (maximum)
4
Circuits Detail
1x4
Color - Resin
Black
Gender
Receptacle
Glow-Wire Compliant
Yes
Keying to Mating Part
None
Lock to Mating Part
Yes
Material - Resin
Nylon
Number of Rows
1
Packaging Type
Bag
Panel Mount
No
Pitch - Mating Interface (in)
0.248 In
Pitch - Mating Interface (mm)
6.30 mm
Pitch - Term. Interface (in)
0.248 In
Pitch - Term. Interface (mm)
6.30 mm
Polarized to Mating Part
Yes
Stackable
No
Temperature Range - Operating
-40°C to +105°C
Material Info
Old Part Number
1991-4R1-1
Reference - Drawing Numbers
Product Specification
PS-02-09
Sales Drawing
SD-1991-4**1
ELV and RoHS
Compliant
Contains SVHC: No
Halogen-Free
Need more information on product
environmental compliance?
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
1991 Series
Mates With
50-36-1743 Pin and Socket Plug
Use With
Terminals, 1380 Male Crimp Terminals,
Terminals, 1434 Male Crimp Terminals,
This document was generated on 12/01/2009
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
