305.000 MHz SAW Filter
RF Monolithics, Inc.
RFM Europe
1999 by RF Monolithics, Inc. The stylized RFM logo are registered trademarks of RF Monolithics, Inc.
Phone: (972) 233-2903
Phone: 44 1963 251383
Fax: (972) 387-8148
Fax: 44 1963 251510
E-mail: info@rfm.com
http://www.rfm.com
SF2110D-091406 Ver 0.1
Page 5 of 6
8-Terminal Ceramic Surface-Mount Case
3.8 X 3.8 mm Nominal Footprint
SM3838-8 Case
TOP VIEW BOTTOM VIEW
Electrical Connections
Connection
Differential Input
Differential Output
Ground
Terminals
1, 2
5, 6
All Others
Return is Ground
Return is Hot
Port 1
Port 2
Single Ended Operation
Differential Operation
Dot Indicates Pin 1
0.066
(1.68)
0.055 TYP.
(1.40)
0
(
0
(
0
(
0
(
0
(
PCB Footprint
Materials
Solder Pad
Termination
Au plating 30 - 60 uInches (76.2-152 uM) over 80-200
uInches (203-508 uM) Ni.
Fe-Ni-Co Alloy Electroless Nickel Plate (8-11% Phos-
phorus) 100-200 uInches Thick
Al
2
O
3
Ceramic
Lid
Body
Pb Free
Case Dimensions
mm
Nom
Max
3.8
4.0
3.8
4.0
1.20
1.35
1.10
1.25
1.00
1.10
0.60
0.70
2.54
2.69
1.75
2.05
Dimension
Inches
Nom
0.150
0.150
0.047
0.043
0.040
0.024
0.100
0.069
Min
3.6
3.6
1.05
0.95
0.90
0.50
2.39
1.40
Min
0.142
0.142
0.041
0.037
0.035
0.020
0.090
0.055
Max
0.157
0.157
0.053
0.049
0.043
0.028
0.110
0.080
A
B
C
D
E
F
G
H
A
1
2
3
B
8
7
6
5
4
C
H7
6
5
4
E
F
G
1
2
3
8
D
6
Y
