June 2000 Rev. 3 - ECO #12894
2
PCMCIA Flash Memory Card
SEA Series
PC Card Products
Pinout
Notes:
1. CD1# and CD2# are grounded internal to PC Card.
2. Shows density for which specified address bit is MSB.
Higher order address bits are no connects (ie 512KB A18 is MSB, A19 - A21 are NC).
3. BVD1 is an open drain output with a 10K ohm internal pull-up resistor.
Pin Signal name I/O
1
GND
2
DQ3
3
DQ4
4
DQ5
5
DQ6
6
DQ7
7
CE1#
8
A10
9
OE#
10
A11
11
A9
12
A8
13
A13
14
A14
15
WE#
16
N.C.
17
Vcc
18
N.C.
19
A16
20
A15
21
A12
22
A7
23
A6
24
A5
25
A4
26
A3
27
A2
28
A1
29
A0
30
DQ0
31
DQ1
32
DQ2
33
WP
34
GND
Function
Ground
Data bit 3
Data bit 4
Data bit 5
Data bit 6
Data bit 7
Card enable 1
Address bit 10
Output enable
Address bit 11
Address bit 9
Address bit 8
Address bit 13
Address bit 14
Write Enable
Active
Pin Signal name I/O
35
GND
36
CD1#
37
NC
38
NC
39
NC
40
NC
41
NC
42
NC
43
VS1
44
N.C.
45
N.C.
46
A17
47
A18
48
N.C.
49
N.C.
50
N.C.
51
Vcc
52
N.C.
53
N.C.
54
N.C.
55
N.C.
56
N.C.
57
VS2
58
N.C.
59
N.C.
60
N.C.
61
REG#
62
BVD2
63
BVD1
64
NC
65
NC
66
NC
67
CD2#
68
GND
Function
Ground
Card Detect 1
Data bit 11
Data bit 12
Data bit 13
Data bit 14
Data bit 15
Card Enable 2
Voltage Sense 1
Active
I/O
I/O
I/O
I/O
I/O
I
I
I
I
I
I
I
I
I
O
I/O
I/O
I/O
I/O
I
I
O
LOW
LOW
LOW
N.C.
LOW
I
I
I
I
I
Address bit 17
Address bit 18
Address bit 19
Address bit 20
Address bit 21
Supply Voltage
512KB(2)
LOW
Supply Voltage
I
I
I
I
I
I
I
I
I
I
I
Address bit 16
Address bit 15
Address bit 12
Address bit 7
Address bit 6
Address bit 5
Address bit 4
Address bit 3
Address bit 2
Address bit 1
Address bit 0
Data bit 0
Data bit 1
Data bit 2
Write Potect
Ground
128KB(2)
Address bit 22
Address bit 23
Address bit 24
Address bit 25
Voltage Sense 2
O
N.C.
O
Extended Bus Cycle
Low
I
O
O
I/O
I/O
O
O
Attrib Mem Select
Bat. Volt. Detect 2
Bat. Volt. Detect 1
Data bit 8
Data bit 9
Data bit 10
Card Detect 2
Ground
Low
(3)
I/O
I/O
I/O
O
HIGH
LOW
